Underground Duct Bank Survey Telecom: What the Survey Proves
An underground duct bank survey telecom assignment verifies the existing conduit path before fiber placement. Each manhole-to-manhole span has 2 endpoints that must be matched to the same duct. We document available capacity and condition, then return authorized rod and mandrel results so engineering can assess the proposed cable route.
Define the span before sending the field team
A survey scope should identify the candidate duct path, not merely a street containing underground plant. We start with the owner's structure identifiers and compare those records with the proposed cable alignment. Where the records disagree, the assignment carries the discrepancy into the field. Quietly choosing the newest drawing would hide the very question the visit needs to answer: which structure actually receives this conduit?
Access and testing authority determine what the visit can establish. The owner must authorize work around occupied facilities and define which pathways may be tested. Qualified personnel perform physical proving under the applicable work procedures; our engineering review uses their recorded results. An inaccessible endpoint remains unverified. A schedule entry saying the survey is complete cannot turn a locked structure into a confirmed receiving location.
We separate pathway survey from permission to install. The owner may reserve a visibly empty duct for maintenance, or a usable innerduct may belong to another operator. Our report carries that restriction beside the physical observation. For the broader records review that precedes this visit, the existing OSP infrastructure survey guide explains how inherited plant enters an engineering assessment.
Keep route location separate from connection proof
Endpoint continuity and underground alignment answer different questions. A rod emerging at the receiving manhole supports a connection between identified openings, but it does not establish the duct's horizontal route or depth between them. We retain the mapped alignment's source. Where the design needs better location evidence, qualified locating or further investigation must address that gap before the alignment is used for conflict decisions.
A straight line joining surveyed covers is especially easy to overread. The buried duct may change direction outside either structure, and the route length can differ from the distance between cover coordinates. We label the length by its measurement method and reference points. Wall-to-wall length and a rod counter reading are not interchangeable; entry offsets and slack must be understood before either becomes a cable quantity.
Location evidence belongs with the duct record without being promoted beyond its limits. Our subsurface utility GIS guide covers how investigation sources and uncertainty reach design. We keep that mapping question separate here: proving a traversable conduit does not locate every buried bend, and mapping an alignment does not establish that a cable can pass through it.
Duct size must retain its source. We distinguish a dimension measured at the accessible opening from a nominal size copied from an owner record, and we identify the material where it can be established. An obscured marking stays unreadable. Guessing the bore from an exterior view can send the wrong proving tool to the span.
The receiving engineer needs a clear distinction between a completed observation and an unresolved dependency. We use the evidence below to decide what can advance into design and what requires another action. The table is a review map, not a substitute for the underlying photographs or test record; each row points to a different failure that a clean route drawing can conceal.
| Survey question | Field evidence | Design consequence |
|---|---|---|
| Where does the duct terminate? | Matched openings and witnessed end-to-end confirmation | Resolve an unconfirmed connection before assigning the span |
| What capacity is present? | Duct inventory with nested innerduct occupancy | Check physical space and owner allocation separately |
| What condition was observed? | Photographs tied to a location and visibility limit | Scope investigation or repair without guessing the buried defect |
| What passed the proving test? | Rod result and mandrel dimensions against owner criteria | Use the result only for the tested path and configuration |
Match the Entry Duct to the Receiving Manhole
Fix the viewing direction on every duct face
Set the orientation before photographing ducts. We want the wall identified and the viewer's direction stated so the drawing cannot be mirrored during drafting. Row and column labels work only when the whole team reads them from the same viewpoint. A close photograph of an opening is useful for condition, but the wider wall view is what lets the designer put it back in context.
Identify the far-end opening separately. Do not assume the upper-left duct at the departure manhole arrives in the upper-left position at the next structure. Crossovers or earlier modifications can defeat that assumption. We pair the actual endpoints in the span record, preserving any difference from the owner drawing so a later designer does not restore the old pairing while cleaning up the CAD file.
Record the witnessed connection
A rodding record should say where the authorized operation began and where the rod was observed to arrive. Identify both tested openings. If the rod stops, we need the insertion distance from a stated reference point and the circumstances of the stop. Resistance alone does not establish a collapse, and it does not justify forcing equipment through an occupied system.
An unwitnessed receiving end leaves partial evidence. A rod fed into a conduit for an estimated span length is not the same evidence as a witnessed arrival. The distinction matters when several candidate structures appear on the records. The report should leave the destination unresolved until there is evidence for the connection, rather than assigning the nearest cover because its location seems plausible.
Photograph the orientation reference with the duct face. A marked opening without its wall orientation can become a different duct when the receiving team redraws the view. Keep the reference in the image set so the pairing survives the move from field notes to CAD.
Count Capacity and Describe the Condition You Can See
Keep innerduct inside its parent duct record
The inventory distinguishes the parent conduit from the innerduct installed within it. Record both visible configurations. Reconcile any difference. An innerduct count is not an extra count of full-size ducts. The design needs to know which innerduct occupies which parent opening, and whether that same innerduct has been identified through the span selected for the proposed fiber.
Occupancy deserves a precise description. A visible cable makes an opening occupied; it does not establish the cable's service status or the owner's permission to place another cable beside it. Where labels cannot be verified, we carry the identity as unknown. Empty-looking innerduct also remains subject to continuity testing and allocation approval. Usable capacity is a design decision supported by those separate findings.
Our field schedule has a limitation. A single capacity cell encourages the reviewer to compress visible vacancy and installation permission into the same answer. We keep those findings separate. This is where field survey for existing telecom pathways supports engineering: the designer can see why an apparently spare duct is still unavailable.
Describe the observation before naming a repair
Water at an opening and sediment inside a duct are useful observations when their locations are recorded. They do not tell us the condition of the entire buried span. We attach photographs to the relevant duct and state the limits of visibility. Where a defect is suspected beyond the opening, the engineer can request the investigation needed to distinguish a local obstruction from a longer damaged section.
Occupied pathways need particular care because a test can affect existing service. We do not treat the visible space around a cable as permission to rod or mandrel the parent duct. The approved method must fit. If the selected path cannot be tested safely within the authorized scope, its proving result stays untested and the design carries the unresolved constraint.
Make condition notes usable by others. A comment such as blocked near the far end needs a reference point before it helps a repair planner. We keep the original observation and identify the proposed follow-up separately. A repair description written too early can steer the next crew toward excavation when the actual cause has not yet been established.
Read Rod and Mandrel Results Against the Proposed Cable
A rod pass and a mandrel pass answer different questions
A flexible rod can traverse a restriction that a larger proving tool cannot. That is why we do not accept rod passed as shorthand for cable ready. The mandrel record must name the tool's diameter and length, with the applicable owner acceptance criteria. Without those dimensions, another engineer cannot determine what clearance the successful passage demonstrated or whether the test applied to the intended innerduct.
The selected mandrel follows the owner's requirements for the actual conduit system. There is no project-independent diameter we can assign from a nominal duct label alone. The qualified testing crew records the result against the approved procedure. A failed passage is retained as a failed attempt even if authorized cleaning or repair later permits a successful retest; the design needs the final condition and the history that explains it.
Keep the mandrel dimensions beside the pass result. A pass entry copied into a spreadsheet without its tool size loses its engineering meaning. Attach the original test record to the duct span so the reviewer can check the result against the proposed installation.
BORVEX's Handhole-to-Handhole Conduit Planning for OSP and Telecom Routes, updated August 22, 2026, identifies owner specifications and provider acceptance as controls on reuse of existing conduit. Its pathway guidance also distinguishes duct continuity from installation-method fit. That is a useful boundary for this survey: our evidence informs the cable design, while the owner's applicable requirements determine what the proving work must demonstrate.
Leave cable placement checks with engineering
A mandrel pass is not a pulling calculation. We still evaluate the selected cable against the installation geometry and the manufacturer's limits. Bends that permit the test tool to pass can still matter to pulling tension and sidewall pressure during placement. For an air-assisted installation, the applicable duct-system requirements need their own review; a mechanical passage test alone does not establish suitability for that method.
The test date also matters when work continues around the route. A verified duct can be affected by later activity before cable placement starts. We flag the interval and any known changes for the installation plan instead of treating the survey result as permanent acceptance. The owner determines whether further proving is needed under the project requirements before the cable enters the system.
Underground Duct Bank Survey Telecom: Release the Findings to Design
Keep each design choice traceable to its span
The handoff should let a designer move from the route drawing to the supporting record without guessing a filename. We bind the duct pairing to the relevant field evidence and retain the source date. The CAD or GIS feature carries the same span identifier. If the connection is unconfirmed, that status remains visible in the design file rather than disappearing inside a detached survey report.
Open questions need an action that could actually close them. A missing allocation decision goes back to the facility owner; an unwitnessed endpoint needs an authorized confirmation. Separate those requests from proposed repairs. The field survey data management guide explains how the original observations remain traceable when corrected information arrives and a revised package goes to engineering.
We also check continuity across spans. A usable duct between the first pair of manholes does not establish a usable route through the next pair. The designer must be able to follow the intended path through each structure without an unexplained change of opening or occupancy. We release supported portions for their intended design use while keeping unresolved connections explicit.
Choose the next action by the owner's decision
ISP reusing an inherited duct route: establish ownership and allocation before committing the cable assignment. Commission proving for the candidate path, with each receiving opening confirmed. A full inventory of visible ducts helps future planning, but it cannot replace evidence for the specific span sequence your build will use. Keep the candidate route conditional until its missing connections are resolved.
Network owner preparing a placement package: require the final proving record to identify the tested configuration. Return a generic clear duct note for clarification before it enters the installation documents. Your receiving designer needs enough evidence to check the cable choice, and the placement contractor needs to know which path was accepted for that review. Neither should have to reconstruct the test from an email.
Program manager facing blocked spans: separate investigation from repair authorization. Obtain the evidence needed to choose between restoring the existing pathway and designing another route. Draftech's engineering is 100% in-house; where approved work proceeds to construction, we provide full turnkey delivery through Draftech-managed subcontract crews. Our engineering and construction services connect that decision to an accountable delivery scope.
